Key attributesDescription：
| Model Number | STN1220 |
| Application | Hotel, Apartment |
| Design Style | Modern |
| Place of Origin | Guangdong, China |
| Brand Name | OEM/ODM |
| Type | Air Conditioning |
| Backlight | Blue/Green/white |
| Color | White |
| After-sale Service | Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement, Other, NONE |
| Project Solution Capability | graphic design |
| Warranty | 1 Year |
Specification：
| Stages | 2 Heat / 2 Cool |
| Programmability | Non-Programmable: 4 times / 4 temp,“WAKE” “LEAVE” “RESTRN” “SLEEP” |
| Low battery indicator | Under 2.7 V (without 24V power supply) |
| Load rating | 1.0Amp per terminal, 1.5Amp maximum all terminals combined |
| Fan Switch | AUTO/ON |
| System Switch | Heat/OFF/Cool |
| Differential | 0.2 to 2.0℉ |
| Display accuracy | ±1℉(under 68℉) |
| Switchable Voltage | 24 VAC(18 to 30 VAC), 50/60 Hz 2*AAA 1.5V Alkaline batteries power |
| Temperature Range | 32℉ to 99℉ (1℃ to 40℃) |
| Setpoint Range | 44℉ to 90℉ (7℃ to 32℃) |
| Installation | Surface Mounting |
| Dispaly | 4.6 sq.Inch |
| Dimensions | 120 x 98 x 28 MM |
Product Description：
>> 2 Heat / 2 Cool
>> 24 VAC(18 to 30 VAC), 50/60 Hz
>> 2*AAA 1.5V Alkaline batteries power
>> Non-Programmable
>> 32℉ to 99℉ (1℃ to 40℃)
>> Blue/Green/white backlight
>> HEAT/OFF/COOL
>> 120 x 98 x 28 MM
