Key attributesDescription：
| Model Number | ST2601RF |
| Application | Underfloor heating system |
| Material | Anti-flammable PC +ABS |
| Place of Origin | Guangdong, China |
| Brand Name | OEM/ODM |
| Type | Floor Heating Parts |
| Certification | RoHS CE CCC |
| Backlight | Blue/White |
| Color | White |
| Screen | Digital LCD |
| Function | Temperature Control |
| Communication RF | 868MHZ 433MHZ |
Specification：
| Programmability | Non-Programmable |
| Power Supply | DC 2 x AAA 1.5V Alkaline batteries |
| Display accuracy | ±1°C (at 20°C) |
| Switchable Voltage | 24 V AC / DC,…250 V AC; 50 Hz |
| Switchable Current | 6 A (2 A inductive load) |
| Temperature Range | 0°C-40°C in 0.1°C |
| Setpoint Range | 5°C-35°C in 0.5°C |
| Power Consumption | 6W |
| Operating Frequency | 868.35MHZ |
| Transmission Distance | approx. 200m in open terrain |
| Maximum Load | 6(2)A, 230V |
| Dimensions | 130 x86 x30 mm |
Product Description：
• Large, easy to ready clear LCD display
• Various backlight color optional
• HEAT (Heating) / COOL (Cooling) / OFF (Frost Protection)
• Room Temperature Calibration adjustment (in -3~+3°C)
• Switching sensitivity adjustable
• Large dial adjustable button
• Simple to use
• Easy installation
