Key attributesDescription：
| Model Number | S2302 |
| Application | Hotel |
| Design Style | Modern |
| Material | ABS+PC |
| Place of Origin | Guangdong, China |
| Brand Name | OEM |
| Type | HAVC System/Floor Heating Thermostat |
| Certification | CE / RoHS |
| Backlight | Orange / Blue |
| Color | White |
| Function | Temperature Control |
| Package | Cardboard Box |
| After-sale Service | Free spare parts |
| Project Solution Capability | graphic design |
| Warranty | 1 Year |
Specification：
| Programmability | 7 Day Programmable |
| System Switch | Heating/Cooling |
| Power Supply | 2 x AAA 1.5V Lithium batteries |
| Display accuracy | ±1°C (at 20°C) |
| Switchable Voltage | 24 V AC / DC,…250 V AC; 50 Hz |
| Switchable Current | 6 A (2 A inductive load) |
| Temperature Range | 0°C-40°C in 0.1°C |
| Setpoint Range | 5°C-35°C in 0.5°C |
| Installation | Flat Wall mount |
| Storage Temperature | -10°C to +60°C |
| Dimensions | 119 x 80 x 26 mm |
Product Description：
>> 7 Day programmable
>> Blue backlight
>> HEAT (Heating) / COOL (Cooling)
>> 6 Time & 6 Temp,per day
>> Manual override mode
>> Wall mount
>> Room Temperature Calibration adjustment
>> Lock key function
>> Battery power supply
